Input/Output signal |
Input signal : 4xE&M (4Wire) + 1x10/100Base-T RJ45, Output signal : 1xE1(75ohm) |
Standards |
Compatible with IEEE 802.3, IEEE 802.1Q (VLAN), comply with protocol G.703 |
E&M interface |
4xE&M (4Wire) |
Color |
|
E1 Interface |
Interface Standard: comply with protocol G.703; Interface Rate: n*64Kbps±50ppm; Interface Code: HDB3; E1 Impedance:75Ω (unbalance), 120Ω (balance); Jitter tolerance: In accord with protocol G.742 and G.823 Allowed Attenuation: 0~6dBm |
Interface rate |
E1 can support N * 64k (N = 1-32) rate |
Transmission band width / rate |
2M |
FXS/FXO Phone interface |
Ring voltage: 75V Ring frequency: 25HZ Two-line Impedance: 600 Ohm (pick up) Return loss: 40 dB Ring detect voltage: 35V Ring detection frequency: 17HZ-60HZ Two-line Impedance: 600 Ohm (pick up) Return loss: 40 Db
|
Data Interface |
Interface rate: 10/100 Mbps, half/full duplex auto-negotiation Interface Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN) MAC Address Capability: 4096 Connector: RJ45, support Auto-MDIX |
Input / output interface |
Input interface: 4xE&M (4Wire) + 1x10/100Base-T RJ45, Output interface :1xE1(75 ohm) |
Product |
Sepitam-4EM1FE-E1-T/R |
Power consumption |
≤10W |
Input Voltage |
AC180V ~ 260V;DC –48V;DC +24V |
Dimensions (WxHxD) |
483x138x44mm |
Weight |
2500g |
Design / Protection class |
Metal Housing/ IP30 |
Operating Temperature |
10°C ~ +55°C- |
Relative humidity (without condensation) |
95% ~ 5%
|
Warranty Period |
36Month |
