Sepitam-SFP1G-MM-DX-20KM

SFP Madul Multi Mode-Duplex-20km

PartNumber: Sepitam-SFP1G-MM-DX-2KM
PartNumber: Sepitam-SFP1G-MM-DX-2KM
Featured Specifications بیشتر
  • Product : Sepitam-SFP1G-MM-DX-2KM
  • Transmission Distance : 550m/2km
  • Transmission Rate : 1.25Gbps
  • Warranty Period : 12Month
Description

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 550m transmission distance with MMF.

The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.



Similar products

Users rate: SFP Madul Multi Mode-Duplex-20km
0
From 5
Excellent
0 (0%)
Good
0 (0%)
middle
0 (0%)
Not OK
0 (0%)
Poor
0 (0%)
  • Expert review
  • Specifications
  • User comments
بررسی تخصصی

Product Description:

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 550m transmission distance with MMF.

The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Product Sepitam-SFP1G-MM-DX-2KM Transmission Distance 550m/2km
Optical fiber Interface LC Duplex Transmission Rate 1.25Gbps
Communication Standards 850nm VCSEL laser and PIN photodetector
Up to 1.25Gbps data rate operation
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitor Interface
 500m transmission with 50/125µm MMF
300m transmission with 62.5/125µm MMF
Very low EMI and excellent ESD protection
+3.3V single power supply
Operating Temperature 0̊C ~ 70 ̊C
Warranty Period 12Month
