مبدل 30 کانال تلفن (FXS/FXO) بر روی E1 ( مدل: Sepitam-30P on E1 )

PartNumber: Sepitam-30P on E1
PartNumber: Sepitam-30P on E1
Featured Specifications بیشتر
  • Product : Sepitam-30P-E1
  • Input / output interface : 30xFXO/FXS RJ45 onE1(75-12ohm)
  • Warranty Period : 36Month
Description

این محصول یک مبدل تلفن ۳۰ کانال بر بستر E1 می‌باشد که از تکنولوژی FXO و FXS پشتیبانی می‌کند. این دستگاه قابلیت تشخیص وضعیت خط و نمایش آن از طریق نمایشگر  LED  و همچنین قابلیت پشتیبانی از استاندارد HDB3 و Clock Master و Clock Line را به همراه دارد.

Similar products

Users rate: مبدل 30 کانال تلفن (FXS/FXO) بر روی E1 ( مدل: Sepitam-30P on E1 )
0
From 5
Excellent
0 (0%)
Good
0 (0%)
middle
0 (0%)
Not OK
0 (0%)
Poor
0 (0%)
  • Expert review
  • Specifications
  • User comments
بررسی تخصصی

This device is 1U, there 6U rack card type, which provides telephone outputs 30, Equipment electrical part for the whole digital circuits, machine reliability, stability, low power consumption, high integration, small size, easy installation and maintenance. Many customers are telecommunications operators E1 leased lines used in computer networking, this equipment can be rented at the E1 line opened a few road phone, you can make free calls between headquarters and branch offices of this.



مبدل 30 کانال تلفن (FXS/FXO) بر روی E1 ( مدل: Sepitam-30P on E1 )
مبدل 30 کانال تلفن (FXS/FXO) بر روی E1 ( مدل: Sepitam-30P on E1 )
Product Sepitam-30P-E1 FXS/FXO Phone interface :FXS Phone Interface
Ring voltage: 75V
Ring frequency: 25HZ
Two-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB


:FXO Switch Interface
Ring detect voltage: 35V
Ring detection frequency: 17HZ-60HZ
Two-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB
Connector RJ45, RJ45 Color
Dimensions (WxHxD) 485x138x45mm Weight 2400g
Operating Temperature 10̊C ~ 50 ̊C- Relative humidity (without condensation) (no condensation) 5%~95%
Input / output interface 30xFXO/FXS RJ45 onE1(75-12ohm) E&M interface AD: 0dB
DA: 0dB
Two/Four-line Impedance: 600 Ohm
Return loss: 20 dB
E1 Interface Interface Rate: n*64Kbps±50ppm
Interface Code: HDB3
E1 Impedance: 75Ω (unbalance), 120Ω (balance)
Jitter tolerance: In accord with protocol G.742 and G.823
Allowed Attenuation: 0~6dBm
Standard Interface Standard: comply with protocol G.703
Design / Protection class Metal Housing/ IP30 Warranty Period 36Month
Power consumption ≤10W, ≤10W Input Voltage AC 180~260V 50-60Hz - DC-48 / +24
