Sepitam-PI204G-DF-60W

PoE سوئیچ صنعتی 4 پورت 10/100/1000Mbps و 2 پورت آپلینک 1G SFP - استاندارد af/at ( مدل: Sepitam-PI204G-DF-60W )

شناسه کالا: Sepitam-PI204G-DF-60W
شناسه کالا: Sepitam-PI204G-DF-60W
مشخصات برجسته بیشتر
  • Product : Sepitam-PI204G-DF-60W
  • Downlink Ports : 4x10/100/1000Base-T PoE
  • Uplink Ports : 2x1000BaseX SFP
  • Mounting type : Rail mount
  • Warranty Period : 60Months
توضیحات

 این محصول یک PoE سوئیچ 4 پورت، سری صنعتی و غیر مدیریتی بوده که علاوه بر ارتباط بین سیستم ها و ایجاد یک شبکه واحد، توان فوق العاده بالای 60 وات به ازای هر پورت را دارا می باشد. این محصول با پشتیبانی از استاندارد های IEEE802.3at ,IEEE802.3af تا حداکثر 60 وات را به ازای هر پورت پشتیبانی می کند. در پنل جلویی این محصول 4 پورت شبکه Rj45 با سرعت 10/100/1000Mbps و2 پورت SFP به صورت آپلینک با سرعت 10/100/1000Mbps تعبیه شده است و همچنین  دارای LED نشانگر وضعیت کارایی دستگاه می باشد و در پنل بالایی محصول نیز درگاه برق ورودی قرار گرفته که این درگاه از دو منبع به صورت همزمان پشتیبانی می کند. این دستگاه نیاز به برنامه ریزی نداشته و به صورت plug and play نصب می شود.

  • product vendor icon image فروشنده:
    سپیتام
به کمک نیاز دارید ؟
کافیست با ما در میان بگذارید تا شما را راهنمایی کنیم
تماس بگیرید

محصولات مشابه

امتیاز کاربران به: PoE سوئیچ صنعتی 4 پورت 10/100/1000Mbps و 2 پورت آپلینک 1G SFP - استاندارد af/at ( مدل: Sepitam-PI204G-DF-60W )
0
از 5
عالی
0 (0%)
خوب
0 (0%)
متوسط
0 (0%)
نامناسب
0 (0%)
ضعیف
0 (0%)
  • بررسی تخصصی
  • مشخصات
  • نظرات کاربران
بررسی تخصصی

The Sepitam-PI204G-DF-60W is a 60W gigabit industrial UPoE fiber switch. It has 4*10/100/1000M UPOE ports and 1*1000M uplink SFP fiber slot port. Port 1-4 can support the super high power 60W UPOE output, backward compatible with the IEEE 802.3af/at PoE standard. Single-port PoE power is 60W, and the maximum PoE output power less than 250W. As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. It can supply power to POE terminal equipment such as wireless AP, Ip camera, industrial sensor through network cable, and meet the network environment that needs high-density PoE power supply. It is suitable for intelligent transportation, rail transit, electric power, mining, metallurgy and green energy. Industrial scenes such as construction set up a cost-effective and stable communication network.



PoE سوئیچ صنعتی 4 پورت 10/100/1000Mbps و 2 پورت آپلینک 1G SFP - استاندارد af/at ( مدل: Sepitam-PI204G-DF-60W )
PoE سوئیچ صنعتی 4 پورت 10/100/1000Mbps و 2 پورت آپلینک 1G SFP - استاندارد af/at ( مدل: Sepitam-PI204G-DF-60W )
Product Sepitam-PI204G-DF-60W Operating Temperature 40°C ~ 75°C-
Relative humidity (without condensation) 90% ~ 5% Downlink Ports 4x10/100/1000Base-T PoE
Uplink Ports 2x1000BaseX SFP Mounting type Rail mount
PoE Enabled Ports 4x10/100/1000Base-T PoE Dimensions (WxHxD) 119x100x30mm
Weight 880gr PoE Standards ,
Switching Fabric 12Gbps Forwarding Rate 7.44Mpps@64byte
MAC 2K Buffer Memory 2Mb
Communication Standards IEEE802.3 10BASE-T
IEEE802.3i 10Base-T
IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-X
IEEE802.3x
Power Budget 250W
Input Voltage 48-57VDC MTBF 500,000Hours
Management Warranty Period 60Months
Redundancy function Redundant DC power supply Design / Protection class Metal Housing/ IP40
Color Black
