| Product | Sepitam-EDFA-BA-G15P20-C |
|---|
| Operating Temperature | 5C° ~ +55°C- |
|---|---|
| Relative humidity (without condensation) | 95% ~ 5% |
| Storage Temperature | 40C° ~ +85°C- |
| Wavelength Range | Min:1527.8,Typical:1550,Max:1565.6(nm) |
|---|---|
| Input Power Range | Min:-15,Max:5(dBm) |
| Gain Range | 15dB |
| Noise Figure | 5dB |
| Output Power Range | Min:-5,Max:20(dBm) |
| Power consumption | 30w |
| Dimensions (WxHxD) | 177x20x225mm |
|---|
| Warranty Period | 36Months |
|---|
| Product | Sepitam-EDFA-BA-G15P20-C | Operating Temperature | 5C° ~ +55°C- |
| Relative humidity (without condensation) | 95% ~ 5% | Wavelength Range | Min:1527.8,Typical:1550,Max:1565.6(nm) |
| Input Power Range | Min:-15,Max:5(dBm) | Gain Range | 15dB |
| Noise Figure | 5dB | Output Power Range | Min:-5,Max:20(dBm) |
| Dimensions (WxHxD) | 177x20x225mm | Power consumption | 30w |
| Warranty Period | 36Months | Storage Temperature | 40C° ~ +85°C- |
