| Product | Sepitam-EDFA-PA-G25P20-C |
|---|
| Operating Temperature | 5C° ~ +55°C- |
|---|---|
| Relative humidity (without condensation) | 95% ~ 5% |
| Storage Temperature | 40C° ~ +85°C- |
| Wavelength Range | Min:1527.8,Typical:1550,Max:1565.6(nm) |
|---|---|
| Input Power Range | Min:-30,Max:-5(dBm) |
| Gain Range | 25(dB) |
| Noise Figure | 5dB |
| Output Power Range | 20dBm |
| Dimensions (WxHxD) | 177x20x225mm |
|---|
| Warranty Period | 36Months |
|---|
| Product | Sepitam-EDFA-PA-G25P20-C | Operating Temperature | 5C° ~ +55°C- |
| Relative humidity (without condensation) | 95% ~ 5% | Wavelength Range | Min:1527.8,Typical:1550,Max:1565.6(nm) |
| Input Power Range | Min:-30,Max:-5(dBm) | Gain Range | 25(dB) |
| Noise Figure | 5dB | Output Power Range | 20dBm |
| Dimensions (WxHxD) | 177x20x225mm | Warranty Period | 36Months |
| Storage Temperature | 40C° ~ +85°C- |
