Enterprise Managed Switch With 24*1G PoE + 4*10G SFP Ports

PartNumber: Sepitam-PS424G-QXM-L3
PartNumber: Sepitam-PS424G-QXM-L3
Featured Specifications More
  • Product : Sepitam-PS424G-QXM-L3
  • Downlink Ports : 24x10/100/1000 Baase-T PoE
  • Uplink Ports : 4x10G Base-SR/LR
  • Mounting type : Rack mount
  • Warranty Period : 36Months
Description

Sepitam enterprise-grade switches are available in managed, unmanaged, PoE, and non-PoE models. The advanced PoE technology simplifies powering various network devices, and high-capacity switches enhance network scalability. With robust management features, these switches enable Layer 2 protocol configurations, delivering superior network efficiency and security.

  • product vendor icon image Seller:
    سپیتام
?Need Help
.Just let us know and we will guide you

Similar products

Users rate: Enterprise Managed Switch With 24*1G PoE + 4*10G SFP Ports
0
From 5
Excellent
0 (0%)
Good
0 (0%)
middle
0 (0%)
Not OK
0 (0%)
Poor
0 (0%)
  • Expert review
  • Specifications
  • User comments
بررسی تخصصی

The Sepitam-PS424G-QXM-L3 is a 10Gbps layer-3 Managed PoE Switch independently produced by Sepitam. It provides 24*10/100/1000Mbps RJ45 ports, 4*10Gbps SFP+ optical module expansion slots, and one Console port. All RJ45 ports from 1-24 support PoE power supply with each port up to 30W, and also static routing function. It provides fully thoughtful security strategies, complete QoS policies, and abundant VLAN functions, while is quite easy enough to be managed and maintained, perfectly meeting the network building up and accessing requirements from enterprises, communities, hotels, office networks, and campus networks.

Enterprise Managed Switch With 24*1G PoE + 4*10G SFP Ports
Enterprise Managed Switch With 24*1G PoE + 4*10G SFP Ports
Product Sepitam-PS424G-QXM-L3 Operating Temperature 0°C ~ 40°C
Relative humidity (without condensation) 90% ~ 10% non-condensing Downlink Ports 24x10/100/1000 Baase-T PoE
Uplink Ports 4x10G Base-SR/LR Mounting type Rack mount
PoE Enabled Ports Port 1~24 Dimensions (WxHxD) 440x207x44mm
PoE Standards , Switching Fabric 128Gbps
Forwarding Rate 95.23Mpps MAC 16K, Auto-learning, Auto-aging
Buffer Memory 12Mbit Communication Standards IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.1X,
IEEE802.1q , IEEE802.1p, IEEE802.1d, IEEE802.1w, IEEE802.3ad, IEEE802.3af,
IEEE802.3at
Power Budget 370W Input Voltage AC 100-240V, 50/60Hz
MTBF >100000 hour Management
Warranty Period 36Months Configuration Method , , , , , , , , , , , ,
Redundancy function MRPP
ULPP
ULSM
ERPS
RSTP
STP
MSTP
Leayer 3 Feathures DHCP Server
DHCPv6 Server
Route Aggregation
RIP v1/v2
OSPF v2
BGP4
Staking Support up to 8 phy. Stacking
Static Route(IPV4/IPV6)
IPv6 Related Function IPv6 ND Snooping
DHCPv6 Relay
DHCPv6 Snooping
IPv6 SAVI
Security RA
Static Route
MLD v1/V2 Snooping
SNMP over IPv6 Support
HTTP over IPv6 Support
SSH over IPv6 Support
DNS over IPv6 Support
IPv6 ping/traceroute Support
IPv6 Telnet Support
IPv6 Radius+ Support
IPv6 Tacacs+ Support
IPv6 SNTP/NTP Support
IPv6 FTP/TFTP Support
IPv6 IPSec Support
IPv6 ACL
IPv4 Related Function Anti ICMP Attack
ICMP Rate Limit
ICMP Unreachable Drop
DCSCM
Multicast VALN
IGMP SNOOPING V1/V2/V3
Fast Leave
IGMP Proxy
DHCP Client/BOOTP
DHCP Relay
DHCP Snooping
DHCP Option 82/43/60/61/67
Color Black
